Previous model specification

1720 kVA Perkins generator — PL1700

Archived PPG PL1700 Perkins generator reference. Check recorded specifications and compare current PPG alternatives. Contact PPG for a quotation.

Previous PPG range. This page retains the earlier PL1700 specification for reference. It is not a current PPG model and should not be assumed to be the same build. Contact us to confirm availability or a suitable current alternative.

Previous model	PL1700
Engine brand	Perkins
Engine model	4012-46TWG3A
Prime / PRP	1720 kVA
Standby / ESP	1890 kVA
Prime output	1376 kW
Standby output	1512 kW
Alternator brand	Leroy Somer
Alternator model	LSA523S5

Looking for a current generator?

Compare the exact operating duty, voltage and engine configuration, not just the model number. The current PPG range offers open and canopied quotations with updated technical summaries.

Discuss PL1700

Original specification notes

PPG 1720 kVA Perkins Diesel Generator. Model PL1700. Engine Perkins 4012-46TWG3A; V12, Electronic Governor. Alternator Leroy Somer LSA523S5. Controller DeepSea DSE 7310 MKII Auto Start. Power Output 1720 kVA PRP / 1890 kVA ESP; 1376 kW PRP / 1512 kW ESP. Fuel consumption 370 L/h at 75% load. 3 Phase, 380V–415V, 50 Hz, 1500 RPM, power factor 0.8. Fuel tank Optional. Country of Origin United Kingdom. Open type: Length 510cm x Width 216cm x Height 281cm; 10600 kg. Enclosed configuration: 40ft ISO Container.

These notes are retained from the previous PPG catalogue. The current quotation determines the specification and operating limits of any supplied generator.
